Regular price $2,699.00 CAD
Color

TECHNICAL SPECIFICATION

Feature Details
Torque Sensor Included
Per Charge (maximum) 80 miles
Payload Capacity 400 lb.
Hydraulic Brakes Included
Samsung/LG Battery 960 Wh
Motor 750 W Geared Hub Motor
Top Speed 20+ mph
Tire Size 26x4 "
Frame 6061 Aluminum frame
Headset Neco H156EM 28.644-5630
Fork TRAMA FAT34-PLS-26" 100mm travel 15*135mm thru axle
Shock Alloy front suspension fork with lockout and adjustment
Front Wheel Rim: MD-147 264.0"36H12G A/V | Spoke: 12G 255/256L stainless (304M) | Hub: MB015-92 M912G135145W
Rear Wheel Rim: MD-147 26*4.0"36H12G A/V | Spoke: 12G 256/257L stainless (304M) | Hub: GSMB019R-190F-GM14
Tires Kenda 26*4.0
Battery Samsung/LG 48V 20Ah
Display KD718-P LCD display with Type-C charger
Throttle Thumb throttle
Sensors Torque sensor丨shifting sensor丨speed sensor丨brake sensor
Crankset Crankarm: Prowheel 170mm / Chain ring: 44T BCD104
Freewheel Shimano CS-HG201-9 11-36T
Chain KMC E9 EPT 124L
Groupset Shimano Altus M2000 9 speed
Front Brake Tektro HD-E350 hydraulic brake
Rear Brake Tektro HD-E350 hydraulic brake
Rotors Tektro TR180-52 F:180mm R:180mm
Stem Zoom TDS-C269-8FOV 31.8*90mm
Handlebar Promax HB-3188 22.231.8700mm
Seatpost Himiway Seatpost
Saddle Himiway Saddle
Pedal Aluminum pedal
Lights 48V LED light
Kickstand Heavy-duty aluminum kickstand
Range 60-80 miles
Controller 48V/22A
Charger US standard 3.0 A smart charger
Rider Height 5'1" ~ 6'5"
Weight 79 lb. (with battery)
Max. Payload Capacity 400 lb.
