Specifications

Frame & Fork

• Frame: 6061 Aluminum Frame
• Headset: Neco H156EM 28.644-5630
• Fork: TRAMA 26" FAT34-26-HLO, 95mm travel, 9*135mm quick release

Wheels

• Front Wheel:
  • Rim: MD-147, 26*4.0"36H12G A/V
  • Spoke: 12G 255/256L stainless (304M)
  • Hub: MB015-92, M912G135*145W
• Rear Wheel:
  • Rim: MD-147, 26*4.0"36H12G A/V
  • Spoke: 12G 214L stainless (304M)
  • Hub: 48V 750W Himiway hub motor
• Tires: Kenda 26*4.0

Electrical Components

• Battery: 48V 20Ah
• Motor: 750W brushless gear motor
• Display: LCD display with USB charger
• Throttle: Thumb throttle
• Sensors: Torque sensor, speed sensor, brake sensor
• Controller: 48V/22A
• Lights: 48V LED light

Drivetrain

• Crankset:
  • Crankarm: Prowheel EB-01-242A-S1 170mm
  • Chainring: 44T BCD104
• Freewheel: Shimano MF-TZ500-7, 14-28T
• Chain: KMC Z8.3 EPT 120L
• Groupset: Shimano Altus M310, 7-speed

Brakes

• Front Brake: Tektro HD-E3520 hydraulic brake
• Rear Brake: Tektro HD-E3520 hydraulic brake
• Rotors: Tektro TR180-52, 180mm (Front and Rear)

Cockpit

• Stem: Promax MA-400, 28.690E10D*41H
• Handlebar: Promax HB-3188, 22.231.8700mm
• Seatpost: Himiway Seatpost
• Saddle: Himiway Saddle

Pedals & Kickstand

• Pedals: Aluminum pedals
• Kickstand: Heavy-duty aluminum kickstand

Performance

• Range: 60-80 miles
• Rider Height Compatibility: 5'3" to 6'5"
• Weight: 79 lbs
• Max Payload Capacity: 400 lbs

Charger

• Charger: US standard 3.0 A smart charger
